Products·In-Ceiling Series

Aspen 6

In-Ceiling Speaker

Aspen 6 brings subtle enveloping audio to small and medium rooms. Installs cleanly, vanishes visually.

XSP-IC-AS6
100W8Ω50Hz – 22kHzPassive
WhiteCustom RAL
Add to System →Brochure

Pricing is quoted by your regional distributor. Find yours →

Move cursor to illuminate
Design Philosophy
×
No pointing requiredThe Aspen 6 is a coaxial point source — tweeter and woofer share a single acoustic centre. Every seat in the room receives identical timbre, identical imaging. There is no sweet spot because the entire room is the sweet spot.
×
No orientation constraint
×
No baffle-step colouration
×
No paint masking
→
50Hz to 22kHz. One cutout.
01 / 05
Contents7 sections

Technical Specifications

20 parameters · scroll to explore
Power RMS
100W
fills a large living room
01 / 20
Acoustic
Power RMS
100W
Impedance
8Ω
Sensitivity
87dB
Frequency
50Hz – 22kHz ±3dB
Driver
1 × 6"
Driver Material
Graphite Cone Woofer
Physical
Diameter
248.4 mm
Weight
1.9kg
Housing
ABS
Colours
White
Custom RAL
+20% · 45–60 days
Power Type
Passive
Cutout Ø
208.9 mm
Cavity Depth
115mm
Paintable Grille
Yes
Grille Material
Mild Steel
Crossover
Built-In Passive Crossover (2-way)
Max SPL
108dB
THD+N
≤0.2% @ 1W/1m
Connectivity
THD+N
≤0.2% @ 1W/1m
Acoustic Measurements

Frequency Response & Directivity

Frequency Response
On-axis · 1W/1m · 50Hz – 22kHz ±3dB · 87 dB sensitivity
Polar Pattern
Normalised polar response · H 110° / V 110° (−6 dB @ 1 kHz)
Proprietary Technology

Built different. By design.

Full Technology Story
PsySculpt
XS-Flow
Nano Resonance
PrecisionXover Array
AeroFrame Chassis
PowerDense Dynamics
Pairs With

Built to work together

Isometric studio shot of the compact XSCACE Air Amp multiroom streaming audio amplifier, engineered for custom architectural audio systems.
Amplifier Series
Air Amp
80W · 8Ω
view of the XSCACE Juniper deep-bass subwoofer sitting on rubber isolation feet on a hardwood floor, highlighting its powerful exposed woofer cone engineered for immersive home audio.
Subwoofer Series
Juniper
350W · 8Ω · 92dB
A modern contemporary living room setup highlighting two black XSCACE Cedar speakers vertically integrated into natural wood paneling behind a plush beige sofa set.
Slim Array Series
Cedar
100W · 4Ω · 96dB
A full equipment rack of XSCACE Lucifer 8 eight-channel power amplifiers mounted one above another, front panels showing per-channel level controls and status indicators
Amplifier Series
Lucifer 8
250W · 8Ω
XSCACE Sage in-wall speaker — 2-way architectural speaker, 555mm tall slim profile, titanium soft dome tweeter, 45Hz–22kHz
In-Wall Series
Sage
150W · 8Ω · 88dB
A technical product graphic showing the physical dimensions of the XSCACE Bergenia in-wall speaker, indicating a height of 13.77 inches and a width of 10.00 inches for the micro-perforated white metal grill.
In-Wall Series
Bergenia
80W · 8Ω · 86dB
In Use

Common installations

2.1 Music Setup · In-ceiling stereo + sub + amp
Source
AVR
Any AVR
Dolby Atmos
Home Cinema 5.1.2 · In-ceiling LCR + surrounds + Atmos + sub
Sound Simulation
Don’t see your setup?
Draw your own room, place this speaker in it, and see the predicted coverage before you specify.
Install Guide ↓Build My System →
Technical Reading

Engineering notes.

Engineering notes and technical background on the Aspen 6 — how it is built, measured and configured.

How Do In-Ceiling Speakers Get Power?
Article
How Do In-Ceiling Speakers Get Power?
No socket in the ceiling, no switch, no plug — passive speakers take an amplified signal down two conductors. …
What Are the Disadvantages of In-Ceiling Speakers?
Article
What Are the Disadvantages of In-Ceiling Speakers?
Sound from above, a permanent hole, limited bass, leakage into the room upstairs and an installation you canno…
From Floor Plan to Quote in One Afternoon
Article
From Floor Plan to Quote in One Afternoon
How the XSCACE Floorplan Sound Simulation turns a plan into predicted coverage, a bill of quantities and a cli…
How to Specify Architectural Speakers — A Guide for Interior Designers and AV Integrators
Article
How to Specify Architectural Speakers — A Guide for Interior Designers and AV Integrators
The most successful architectural audio projects share one characteristic: the audio system was specified at t…
In-Ceiling Speaker Buying Guide for Luxury Homes
Article
In-Ceiling Speaker Buying Guide for Luxury Homes
In-ceiling speakers: bought correctly, they disappear and fill every room with sound. Bought incorrectly, they…
In-Ceiling Speaker Installation Guide: From Rough-In to Commissioning
Article
In-Ceiling Speaker Installation Guide: From Rough-In to Commissioning
From marking speaker positions before walls close to running PsySculpt™ calibration at commissioning — a compl…
In-Wall vs In-Ceiling Speakers — Which Is Right for Your Project?
Article
In-Wall vs In-Ceiling Speakers — Which Is Right for Your Project?
In-wall and in-ceiling speakers are both architectural — but mounting position changes the acoustic character …
Mobile App
XSCACE Controller
iOS & Android
XSCACE Controller
When paired with Air Amp or Air Mini, control this speaker from your phone. Volume, sources, multiroom groups, a 10-band parametric EQ, and X-Sense AI room calibration that maps the room as you walk it — all in one app.
Learn more →
Gallery

Aspen 6 in context

Scroll
Aspen 6 1
Aspen 6 2
Aspen 6 3
Aspen 6 4
Aspen 6 5
Aspen 6 6

The Aspen 6 pairs a 6-inch woofer with a 1-inch silk soft dome tweeter for a frequency range of 50Hz–22kHz and 100W of headroom — sized for bedrooms, dining rooms, and small offices up to 18×18 ft. Its in-ceiling profile disappears into a standard ceiling cavity while delivering clear, detailed sound across the full listening range.

Frequently asked questions5 answers
What is the XSCACE Aspen 6?

Widely specified for residential multi-room audio, hospitality background music, and commercial retail environments across the UK, Europe, and India.

What is the frequency response of the Aspen 6?

The Aspen 6 covers 50Hz–22000Hz (±3dB).

What is the power output of the Aspen 6?

The Aspen 6 is rated at 100W RMS into 8Ω.

Is the Aspen 6 an in-ceiling, in-wall, or slim-array speaker?

The Aspen 6 is an in-ceiling product, mounted via Spring clip.

How deep is the Aspen 6?

The Aspen 6 requires 107.95mm of depth (115mm cavity), engineered to sit as close to flush as the driver geometry allows.
